SPECIFICATIONS

● Swing angle > 100 ° or multi-turn (without end stops)

● Worm wheel made of bronze for modulating applications

● Clockwise rotation at the input shaft results in counterclockwise rotation at the output drive

● Base and lever

● Chain drive

● Housing made of spheroidal cast iron

● Version for drinking water applications

● Version for nuclear power plants

● Fireproof K-MASS® coating

● Extension flange IM1 to IM3 version in accordance with EN ISO 12944-2

● Housing made of spheroidal cast iron

FEATURES

● Torque range up to 675,000 Nm

● Reduction ratios from 39:1 to 3328:1

● Swing angles up to 190°

● With or without primary reduction gearing

● 360° worm wheel

● End stops with travelling nut principle in accordance with AWWA C504

● Output drive according to ISO standard

● Adjustable end stops

● SIL parameters

● All parts within the power drive have been subjected to thermal hardening
